B098H Aluminum Alloy Rail-mounted Force Sensor Signal Transmitter Amplifier

Specifications

Technique

Output specification

0.01%

Output linear

0.005%

Division

65000

CO., of temperature

±25ppm/℃

Input load

1～4 load cells

Excitation voltage

10VDC

Output

±10V、4～20mA、0～20mA

Output load

Voltage load≥2KΩ

Current load≤500Ω

Power supply

16～32VDC

Power waste

≤3W

Operation temp range

-20~60℃

Weight approx.

0.45kg

Material

Aluminum ally

IP Class

IP66
DOWN LOAD
INQUIRE

Product Description



Features & Applications

l   Multi-output ±10V,4～20mA,0～20mA

l   The power is isolated from signal, strong anti-interference ability.

l   High accuracy, high precision amplifying and resistance

l  Stable and accurate output with multi-grades active filter.

l   Could be connected with multi-capacity load cells with wide scope of zero point adjustment





Specifications

Technique

Output specification

0.01%

Output linear

0.005%

Division

65000

CO., of temperature

±25ppm/℃

Input load

1～4 load cells

Excitation voltage

10VDC

Output

±10V、4～20mA、0～20mA

Output load

Voltage load≥2KΩ

Current load≤500Ω

Power supply

16～32VDC

Power waste

≤3W

Operation temp range

-20~60℃

Weight approx.

0.45kg

Material

Aluminum ally

IP Class

IP66
