Side-installed 1kg~3kg Single Point Load Cell For Dynamic Weighing WL-119

DOWN LOAD
INQUIRE

Product Description

Features & Applications:

  1.    Single point load cell

  2.    Made of Aluminum alloy

  3.    Maximum capacities loads 1kg...30kg

  4.    High precision,easy installation with Max.platform size up to 200mm*200mm

  5.    Different cable lengths and other options available

  6.    Suitable for electric pricing scale, electronic package scale and other electronic weighing devices.



Specifications:

Specifications

Technique

Capacity

1~30kg

Rated output

1.0±20%mV/V

Zero balance

±0.04mV/V

Non-linearity

0.017%F.S.

Hysteresis

0.017%F.S.

Repeatability

0.017%F.S.

Creep(30min)

0.017%F.S.

Temp.effect on output

0.02%F.S./10℃

Temp.effect on zero

0.02%F.S./10℃

Input impedance

405±10Ω

Output impedance

350±3Ω

Insulation

≥5000MΩ/100VDC

Recommended excitation

5~15V

Maximum excitation

15V

Compensated temp range

-10~40℃

Operation temp range

-10~50℃

Safe overload

150%F.S.

Ultimate overload

300%F.S.

Material

Aluminum alloy

IP Class

IP66
