3/6/10/20/30kg C3/C4 Single Point Load Cell WL-114

Features & Applications:

1. Single point load cell

2. Made of Aluminum alloy

3. Maximum capacities loads 3kg...30kg

4. High precision C3/C4 optional

5. With good consistency of rated output, can be used in parallel with multiple units

6. Mainly used for small weight range applications,such as batching,filling and production quality control of micro-dispensing metering,medicine,cosmetics,food packaging and other small

packages

Specifications:

Specifications	Technique
Capacity	3,6,10,20,30kg
Rated output	2.0±10%mV/V
Zero balance	±0.02mV/V
Non-linearity	0.015%F.S.
Hysteresis	0.015%F.S.
Repeatability	0.02%F.S.
Creep(30min)	0.017%F.S.
Temp.effect on output	0.02%F.S./10℃
Temp.effect on zero	0.02%F.S./10℃
Input impedance	405±10Ω
Output impedance	350±3Ω
Insulation	≥5000MΩ/100VDC
Recommended excitation	5~15V
Maximum excitation	15V
Compensated temp range	-10~40℃
Operation temp range	-20~60℃
Safe overload	150%F.S.
Ultimate overload	300%F.S.
Material	Aluminum alloy
IP Class	IP65
